Compressed air magnetic stirrer drives with flange
Permanent magnetic coupling and a flanged
PMRK series drives feature a permanent magnetic coupling and a flanged, compressed air-driven motor. The use of a cardan coupling is unnecessary, meaning both vibrations and the installation height are reduced.
The flange version is suitable for applications under vacuum and pressure up to 10 bar. The advantage of a flange connection is that forces are distributed over a larger contact surface, allowing the use of higher torques and larger container volumes.
The speed is regulated by a continuously adjustable fine control valve, with an analogue tachometer fitted as standard.
Ball bearings ensure rapid, easy replacement to facilitate maintenance and cleaning.
The speed is regulated by a continuously adjustable fine control valve, with an analogue tachometer fitted as standard.
Ball bearings ensure rapid, easy replacement to facilitate maintenance and cleaning.
Technical details
Volume (max.)
Up to 5 liter
Up to 10 liter
FFlange
DN 15
DN 25
DN 40
Special flanges according to your specifications
Pressure (max.)
Up to 10 bar
Up to 200 bar
Up to 700 bar
Torque
Up to 8 Ncm
Up to 90 Ncm
Up to 150 Ncm
Materials
Stainless steel 1.4571
HC22® 2.4602
More on request
Bearings
Ball bearings stainless steel
Slide bearings PTFE/carbon
ATEX certification
On request
Special versions tailored to your wishes
Yes
No
